| CNC-controlled Creep Feed Profile Grinding Center FSM TFc |
|
 |
| PART |
ITEM |
SPECIFICATION |
| projection |
Field of view |
500 x 250 mm |
| |
Magnification |
10x, 20x, 50x |
| Illumination |
Cold light source |
12 V, 100 W |
| Grinding Head |
Rotational CNC axis, |
Z ±30° |
| Inclination |
α -15° |
| Grinding Storke |
Length, steplessly variable |
W2 0-78 mm |
| Grinding Head |
Spindle motor |
2.5 kW |
| Spindle speed |
1'500 - 6'000 rpm |
| Grinding diameter |
max. 300 mm |
| Bore diameter |
46 H6 |
| Travel Range |
Profile width, CNC-axis |
X 120 mm |
| Profile depth, CNC-axis |
Y 50 mm |
| Resolution |
Linear axis |
0.0001 mm |
| Rotational axis |
0.001° |
| Workpiece Table |
Table size |
500 x 290 mm |
| Height adjustment |
W1 70 mm |
| Travel in X-direction |
U1 95 mm |
| Travel in Y-direction |
V1 40 mm |
| Work Range: |
|
|
| Flat Form |
Max. profile height |
20 mm |
| Round Form |
Max. workpiece diameter |
200 mm |
 |
- For the fully automatic or manual grinding of form throw
away tips、 flat
form tools、 and circular form tools in carbide、 hardened steel and other
materials as copper、 graphite、 ceramics and so on 。
- All standard accessories and tools can be installed
according to your request 。
|
